Draco

For applications in explosive environments.

Seal of housing hole when no cable gland is used.

Can be used for 7J high impact applications.

To fasten with spanner.

Can be used with intrisically safe circuits.

Up-to-date international approvals.

Suitable for use in	Group II, Group III
Equipment Marking	EX II 2GD Ex eb IIC Gb, Ex tb IIIC Db
Ingress Protection Rating	IP66, IP68 - 5 Bar, 30 min
Cable Gland Material	PA 6 (Polyamide 6)
Seal Material
Operating Temperature	Chloroprene, Silicone
Chloroprene: -40°C to +70°C
Silicone: -60°C to +70°C
Thread Type	Metric, NPT
Other thread types available upon request.
Cable Type	Non Armoured
Accessories	Lock nuts, Gaskets (Washers)
Remarks	Accessories must be ordered separately. O-ring available in Metric outer threads.

		Datasheet	Ordering Code
