Ventilation Cable Glands, Plastic

Combines cable gland functionality with ventilation, providing secure cable retention and pressure equalization within enclosures.

Offers the advantage of using a single enclosure entry hole for both cable connection and ventilation, saving space and simplifying design.

Prevents the formation of water condensation in tightly-sealed standard housings and protects against damage caused by pressure differences.

Provides effective sealing to block ingress of water, dust and contaminants.

Extends the service life of equipment by relieving pressure that would otherwise degrade enclosure gaskets over time.

Manufactured from high-quality, durable materials for long service life.

Suitable for both indoor and outdoor use in industrial environments

Cap/Body Material Polyamide 6 V2 acc. to UL 94
Seal Material Neoprene (Chloroprene)
Membrane Material PTFE / Acrylic Co-Polymer
Gasket Material CR
Ingress Protection Rating IP69, IP68, IP66
Temperature Range -40 °C to +100 °C
Colour Silver grey (RAL 7001)
Light grey (RAL 7035)
Black (RAL 9005)
Thread Type Metric, PG, NPT
Cable Type Non-Armoured
Accessories Locknut
Dome plug
Remarks Accessories must be ordered separately.

Calculate Pressure Compensation
With our vent calculator you can easily and precisely determine your needed air-passage, which is important for the proper function of your system.
